MDVI-14 -- 4 Ports DVI Splitter |
|
|
Features
|
|
|
- Use PanelLink digital technology.
- Supports high-resolution display up to UXGA (25-165 MHz).
- Can be cascaded.
- Compliant with the specification of DVI 1.0.
- 1U rack design.
|
Package Contents
|
|
|
- 1 Smart View DS-814F DVI Splitter.
- 1 DC 7.5V 1.5A Power Adapter.
- 1 User Manual.
- 2 Rack rails, 8 screws.
|
Hardware Requirements
|
|
|
- Monitor
The DVI monitor, DVI projector is capable of the highest resolution(1600x1200).
- PC
Inserted with a DVI display card.
- Cable
Standard cable.
|
Specification
|
|
|
| |
|
Cable Distance(device to monitor)
|
10m max
|
|
Signal Type
|
Standard DVI Signal
|
|
Video Input Connector
|
1 DVI Female
|
|
Video Output Connector
|
4 DVI Female
|
|
DVI Resolution
|
1600x1200 60Hz
|
|
DC Power Adaptor
|
|
|
Voltage
|
7.5V
|
|
Amps
|
1.5A
|
|
Housing
|
Metal
|
|
Weight
|
620g
|
|
Dimensions
|
|
|
Length
|
200mm
|
|
Width
|
75mm
|
|
Height
|
42mm
|
|
|
|
| |
 |
